Sourced, Tested, and Assembled for Precision
PCB Assembly is one of the most critical points in the process of attaining the features and functionalities you seek from your PCB. All the designed features, component innovation, and supply chain efficiencies assimilate at the point of assembly.
We have installed systems throughout the process to maintain the integrity of components and test the quality of the PCB in line with your requirements. Our assembly system runs from placement, soldering, insertion, cleaning, and inspection. We have deployed BOM Component Verification for quality control, along with options of Surface-Mount or Through-Hole Technology, to meet your assembly requirements.
Our Range of Offerings
| Types of PCB Assembly | Surface Mount (SMT), Through-Hole (THT), Mixed Technology (SMT / Through-Hole) Single or double-sided placement |
| Types of Solder | Leaded Lead-free (RoHS Compliant) |
| Minimum Order | No minimum quantity |
| Component Types | Passive Components, as small as 01005, 0201, 0402 Fine Pitch Parts (QFN, QFP) Small Chip Packages, 01005 Max. Size: 56 X 56 X 15 mm |
| Component Package | Reels Cut Tape (must be continuous and 12 inches or longer) Tube & Tray Max Customer Panel Size – 270 mm x 370 mm |
| Board Dimension | Min Board Size: 90mm x 50mm (Boards smaller than this will be panelized) Min. Board Thickness: 0.5 mm Max. Board Thickness: 3.20 mm |
| Board Shape | Rectangular, Circular and other Custom Shapes. (For shapes other than rectangle, we will panelize the boards in an array, and add panel border on at least two of the longer sides.) |
| Board Type | We work only with Rigid Boards. |
| Inspection + AOI | Visual X-ray |
| Supported File Formats | BOM: .xls, .csv, .xlsx Gerber (RS-274X) Centroid (XY, Pick-&-Place) |
Range Of Alternatives
Turnkey Assembly We work around the entire schedule and process of ordering components... This ensures:
- 100% Quality Assurance: Each vendor is verified...
- Zero Delays Caused by Miscommunication: Our precise manufacturing process...
- Industry-Standard Outputs: All the PCBs assembled...
OR
Consigned Assembly You can send us the components... control. If you have already run quality testing...
- Short Lead Time: We leverage the collaborative powers...
- Internal Quality Control: If you are maintaining a high standard...
- Retained Proprietary Information: This process is optimal if...
OR
Partially-Consigned Assembly This is an ad hoc arrangement where you can supply a partial list...
- Quick Inventory to Invention Model: If you already have some critical components...
- Comprehensive Quality Observance: This brings the best of both worlds...
